Custom Design LCD Quotation Requisition Sheet
Company Name
Contact Person
Tel
Fax
Email
Application
LCD Type
TN
HTN
STN-Green
STN-Gray
STN-Blue
FSTN
Dimension
Item
Size
Item
Size
A. Width of Glass
E. Viewing Area (H)
B. Front Glass (H)
F. Pitch Size
C. Rear Glass (H)
G. Pin Length
D. Viewing Area (W)
H. Width Between Pin Lines
Glass Thickness :
1.1mm
0.7mm
0.55mm
0.4mm
0.3mm
Note :
Contact Ledge
Others
The bold lines show the terminal electrodes
Viewing Direction
3 o'clock
6 o'clock
9 o'clock
12 o'clock
4:30 or 7:30
LCD Driver
Display Mode
Positive Image
Negative Image
Polarizer
Front :
Pasted
Separated
Normal
Color :
Back :
Pasted
Separated
Reflective
Transmissive
Transflective ( Sem-Transmissive
) Type
Operation Method
Voltage
STATIC
DYNAMIC
Frame Frequency
DUTY
BIAS
Connector
Rubber Connector
Heat-Seal Connector
Straight Pin Connector
Bend Pin Connector
Number of pins :
Temperature Range
Operating Temperature
° C-
° C
Storage Temperature
° C-
° C
